I was called to a site in Nevada where a scissor lift and trailer had parted ways on a highway curve. The lift tipped off the trailer, the trailer tongue jack-knifed, and the whole mess ended up in the median. The operator walked away, but the scissor lift was a write-off, and the trailer frame was bent. That day taught me that moving a scissor lift and trailer combination is not just hook and go. You need the right equipment, the right setup, and the right mindset. Here’s what I learned in thirty years of hauling heavy iron.
Choosing the Right Trailer for Your Scissor Lift
Not every trailer is built for a scissor lift. A typical 26-foot scissor lift weighs between 3,500 and 5,000 pounds, and the trailer you pair it with must have a GVWR well above that. I’ve seen guys try to haul a scissor lift and trailer on a 5,000-pound-rated single-axle utility trailer. That overloads the axle, overheats the bearings, and can snap the spindle. Field Lesson: use at least a 7,000-pound GVWR tandem-axle trailer. Tandem axles give you a safety margin if one tire blows, and they handle the side loads from loading ramps much better than a single axle. Also, make sure the trailer deck is wide enough—minimum 7 feet—so the lift’s outriggers don’t hang over the sides.
Weight Distribution: The Key to Safe Towing
A scissor lift and trailer combination that’s nose-heavy or tail-heavy will fight you the whole way. I once watched a driver struggle to keep a trailer from wagging because he’d centered the scissor lift too far back. The tongue weight dropped to under 5% of the total, and the rear of the tow vehicle started hopping. Nightmare. You want between 10% and 15% of the combined trailer and lift weight on the hitch. For a 5,000-pound lift on a 1,500-pound trailer, that’s 650 to 975 pounds of tongue weight. Use a tongue weight scale to check it, and adjust the scissor lift’s position on the deck accordingly. If your tow vehicle has a Class IV or V hitch rated for at least 10,000 pounds, you’re in good shape. Safety Alert: never overload your hitch receiver — check the sticker on the drawbar for its max tongue load.
Tie-Downs That Won’t Let Go
I’ve seen more scissor lifts come loose from improper tie-downs than any other cause. The scissor lift has a high center of gravity when raised, so you must secure it in its fully lowered position. Use at least four heavy-duty ratchet straps with a working load limit of 5,000 pounds each. Two straps over the base frame at the front, two at the rear. Cross them diagonally to resist forward and lateral movement. Never use bungee cords or light-duty ropes — they’ll stretch and let the load shift. Also, chock the wheels of the scissor lift with rubber wheel chocks on both sides. I prefer the kind with a textured base that grips the trailer deck. Field Lesson: check the straps every time you stop for fuel. Temperature changes and vibration can loosen them.
Loading and Unloading: The Most Dangerous Step
Loading a scissor lift onto a trailer is where most accidents happen. The ramp angle is critical. Too steep, and the scissor lift’s front wheels will climb over the ramp edge or the ramp will slide out from under it. Use ramps rated for at least the scissor lift’s weight, and make sure they’re long enough so the approach angle doesn’t exceed 15 degrees. If you’re loading a boom-type scissor lift, lower the platform fully before driving onto the trailer. I’ve seen a guy forget and a raised platform hit a low beam overhead. That’s a $10,000 mistake. Safety Alert: always have a spotter outside the lift when loading or unloading. The operator can’t see the side clearance from inside the basket. And chock the trailer wheels so it doesn’t rock during the process.
Braking and Maintenance Checks
Once your scissor lift and trailer are loaded and tied down, you’ve got to make sure the trailer brakes are working. Most tandem-axle trailers have electric brakes. Before you hit the highway, do a brake test at low speed in a parking lot. I always check the trailer brake controller on my truck to make sure it’s set for the right gain — typically around 6 to 8 for a loaded trailer. If the brakes feel weak, adjust the controller up a notch, but don’t go so high that the trailer locks up and skids. Also, check tire pressures on both the tow vehicle and the trailer. Underinflated tires on a loaded scissor lift and trailer will overheat and blow out at highway speeds. Field Lesson: carry a spare tire and a jack that reaches the trailer axle. You don’t want to be stranded in the desert with a flat.
Field Lesson: The Cost of Cutting Corners
A friend of mine in Phoenix decided to save a few hundred dollars by renting a trailer that was just barely big enough for his scissor lift. He skipped the weight distribution check and used only two straps. On a downhill grade, the lift shifted, the straps snapped, and the lift went through the trailer bed. He ended up with a destroyed lift, a bent trailer, and a lawsuit from the driver behind him who hit the debris. That incident cost him over $40,000. All because he didn’t treat the scissor lift and trailer as a serious hauling job. If you’re going to move a scissor lift, do it right. Invest in a proper trailer, use the right tie-downs, check your weights, and never skip the pre-trip inspection. I’ve seen this go wrong. Here’s how you avoid it.
Transporting a scissor lift and trailer doesn’t have to be dangerous. Take the time to set up your rig correctly, and you’ll arrive at the job site with both your machine and your reputation intact.
